PEODUCT DESCRIPTION
First, the working principle of the mixing mechanism
The mixing mechanism of Zoomlion Mixing plant is mainly composed of
main engine, reducer, mixing wheel and mixing knife. The main
engine drives the mixing wheel through the motor to rotate, and the
reducer slows down the speed of the main engine and transmits the
force to the mixing knife through the chain and sprocket, so that
it rotates in the hopper to achieve the purpose of mixing. At the
same time, the mixing mechanism can also adjust the speed and
mixing Angle according to different mixing intensity to adapt to
different work needs.
Second, the working principle of the mixing truck
Zoomlion mixer is the core component of mixing station, which is
mainly composed of body, axle, transmission system, hydraulic
system and mixing tank. The mixing tank can hold a certain amount
of concrete raw materials, and when the mixing mechanism starts to
work, the concrete raw materials are mixed under the action of the
mixing mechanism. Once the mixing is complete, a hydraulic system
dumps the concrete from the mixing tank into the delivery pipe for
transport to its destination.
The working principle of the control system
The control system of Zoomlion mixing plant is mainly composed of
electrical system and hydraulic system. The electrical system
realizes the control and monitoring of stirring mechanism,
conveying pipeline, hydraulic system and other parts through PLC
control box, touch screen and sensors. The hydraulic system
monitors the pressure change during the tipping process of the
mixing tank through the pressure sensor and other components, and
controls the piston movement of the hydraulic cylinder to realize
the tipping of the mixing tank and the opening and closing of the
hydraulic door.
The working principle of Zoomlion mixing plant is very simple, but
in practical applications, the mixing plant can achieve simple
adjustment and real-time monitoring of the mixing mechanism through
the control system to achieve more efficient concrete preparation
effect. In addition, the length of the conveying pipeline of the
mixing truck can be adjusted according to the actual situation of
the construction site, and the conveying distance of up to 50
meters will not affect the uniformity and quality of the mixing
concrete, which greatly facilitates the on-site construction.
Technical Parameters:
| PRODUCT NAME | New concrete mixer truck |
| Brand | Zoomlion |
| Color | White+Green |
| model | 7 CBM 20 Cbm 12 Cbm 10 Cbm 8 Cbm 14Cbm |
| Applicable Industries | Machinery Repair Shops, Manufacturing Plant, Construction works ,
Energy & Mining |
| Video outgoing-inspection | Provided |
| Machinery Test Report | Provided |
| Place of Origin | Changsha,Hunan,China |
| UNIQUE SELLING POINT | High operating efficiency |
| Other name | mobile diesel Concrete Transit concrete mixer trucks |
| Engine type | Diesel |
| Price | Negotiable |
| Total mass | Total mass 35000Kg |
| Core Components | PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump |
Product picture
The company specializes in the production of all kinds of high,
medium, low pressure dry, thin oil lubrication equipment, hydraulic
components, fluid connectors, support to map customization, large
volume support logo customization, welcome overseas customers to
come to buy, excellent price, good quality.
Наша компания работает над одноэтажным сервисом аксессуаров,
обеспечивающим идеальное сотрудничество и превосходную
производительность. Это облегчает поиск деталей, подходящих для
вашего насоса, экономит ваше время и энергию.
Under the continuous new strategy, we are committed to bringing
customers a steady stream of new product experience. Through
continuous innovation, we strive to maintain the vitality and
competitiveness of the store, and create more surprises and value
for customers. Stay tuned.
